HP PRO 2000 - Manual (Page 11)

Power Supply Power Supply Power Supply Power Supply
Microtower Microtower Microtower Microtower
Model 250W PFC+HV 300W PFC+HV 300W 85% Eff
Standard Efficiency N/A N/A 300W standard efficiency
active PFC
Energy Efficient N/A N/A 300W 85% efficient
active PFC
Operating Voltage Range 90 to 132VAC, or
180 to 264VAC
90 to 132VAC, or
180 to 264VAC
90 - 264 VAC
Rated Voltage Range 100 to 127VAC, or
200 to 240VAC
100 to 127VAC, or
200 to 240VAC
100 - 240 VAC
Rated Line Frequency 50/60 Hz 50/60 Hz 50/60 Hz
Operating Line Frequency Range 47 - 63 Hz 47 - 63 Hz 47 - 63 Hz
Rated Input Current 8A/4A 8A/4A 8A/4A
115V/230V Line switch Yes Yes N/A
Rated Input Current with Energy Efficient *
Power Supply
N/A N/A 8A/4A
Current Leakage
(NFPA 99) <3.5mA <3.5mA <275 µA
System Heat Dissipation 48.5 W or 165.482
BTU/hr.(For 115V/60Hz)
48.2 W or 164.4584
BTU/hr. (For 30V/50Hz)
50.4W or 171.9648
BTU/hr. (For115V/60Hz)
50.3W or 171.6236
BTU/hr.(For 230V/50Hz)
43.1W or 147.0572BTU/hr.
(For 115V/60Hz) 43.2W or
147.3984 BTU/hr. (For
230V/50Hz)
System Heat Dissipation
with Energy Efficient
* Power Supply
N/A N/A 43.1W or 147.0572BTU/hr.
(For 115V/60Hz) 43.2W or
147.3984 BTU/hr. (For
230V/50Hz)
Power Supply Fan 80mm variable speed 80mm variable speed 80mm variable speed
FEMP Standby Power Compliant
(<2W in S5 - Power Off)
*
0.45W (For 115V/60Hz)
0.53W (For 230V/50Hz) 0.65W (For 115V/60Hz)
0.71W (For 230V/50Hz) 0.17W (For 115V/60Hz)
0.37W (For 230V/50Hz)
Power Consumption in ES Mode - Suspend
to RAM (S3) (Instantly Available PC) <3W <3W <2.7W
High voltage immunity up to 410V/s up to 410V/s N/A
China Telecom YD/T 993-2006 spec Yes Yes N/A
QuickSpecs
HP Pro 2000 Business PC HP Pro 2000 Business PC HP Pro 2000 Business PC HP Pro 2000 Business PC
System Details
DA - 13494 Worldwide — Version 4 — November 29, 2010 Page 11
