PCIe x16 Card

Display max resolution

Analog VGA: 2048x1536x32bpp @ 75Hz &1920x1440x32bpp @ 75Hz
DVI: 2560x1600x32bpp @ 75Hz
HDMI: 1920x1200x32bpp @ 100Hz

Input/Output connectors

Input/Output connectors Dual-Link DVI-I/VGA/HDMI
Board configuration

Board configuration

Specification

Description

Graphics Chip

NVIDIA D10M1

Core clock

600 MHz

Memory clock

500 MHz

Frame buffer

512 MB DDR2, 192bit

Compliance standards

EMC Emissions:

FCC Part 15, Subpart B - Unintentional Radiators, Class B Computing
Devices for Home & Office Use
CISPR22: 1997/EN 55022:1998 - Class B - Limits and methods of
measurement of radio disturbance characteristics of Information
Technology Equipment
Canadian Standard ICES-003 is equivalent to CISPR22
Japanese VCCI
Taiwanese Standard BSMI
Australian C-Tick
Korean (KCC)

EMC Immunity:
CISPR 24:1997/EN 55024:1998 - Information Technology Equipment -
Immunity Characteristics - Limits and Methods of Measurement.

Core power

21 W (Max board power)

NVIDIA G210 (512 MB) PCIe x16 Graphics Controller display resolutions and refresh rates

NOTE:

Other resolutions may be available but are not recommended as they may not have been tested and qualified by HP
All standard VGA text/graphics modes are supported in addition to table below.
All modes not highlighted are selectable Windows® desktop modes. Highlighted modes should
not be selectable as Windows® desktop modes (they are for DirectX™)
All modes up to and including 1600x1200 must support the video overlay at all refresh rates.

QuickSpecs

HP Pro 2000 Business PC

Technical Specifications

DA - 13494 Worldwide — Version 4 — November 29, 2010
