Intel Gigabit CT Desktop Intel Gigabit CT Desktop Intel Gigabit CT Desktop Intel Gigabit CT Desktop
NIC
NIC NIC NIC
Connector Connector Connector Connector RJ-45
Controller Controller Controller Controller Intel WG82574L Gigabit Ethernet Controller
Memory Memory Memory Memory Integrated Dual 48K configurable transmit receive FIFO Buffers
Data rates supported Data rates supported Data rates supported Data rates supported 10/100/1000 Mbps
Compliance Compliance Compliance Compliance IEEE 802.1P, 802,1Q, 802.2, 802.3, 802.3AB and 802.3u compliant,
802.3x flow control
Bus architecture Bus architecture Bus architecture Bus architecture PCI-E 1.0a
Data path width Data path width Data path width Data path width X1, 250 MB/s, Bi-directional interface
Data transfer mode Data transfer mode Data transfer mode Data transfer mode Bus-master DMA
Hardware certifications Hardware certifications Hardware certifications Hardware certifications FCC, B, CE, TUV- cTUVus Mark Canada and United States, TUV- GS Mark
for European Union
Power requirement Power requirement Power requirement Power requirement Aux 3.3V, 3.0 Watts in 1000base-T and 2.0 Watts in 100Base-T
Boot ROM support Boot ROM support Boot ROM support Boot ROM support Yes
Network transfer rate Network transfer rate Network transfer rate Network transfer rate 10BASE-T (half-duplex) 10 Mbps
10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T (full-duplex) 2000 Mbps (actual rate limited by PCI Bus)
Environmental Environmental Environmental Environmental Operating temperature Operating temperature Operating temperature Operating temperature 32° to 131°F (0° to 55° C)
Operating humidity Operating humidity Operating humidity Operating humidity 85% at 131° F (55° C)
Dimensions Dimensions Dimensions Dimensions 4.75 x 2.25 x 0.8 in (12.1 x 5.7 x 2.0 cm)
Management capabilities Management capabilities Management capabilities Management capabilities WOL, PXE, DMI, WFM 2.0
LSI PCIe x1 56K LSI PCIe x1 56K LSI PCIe x1 56K LSI PCIe x1 56K
International SoftModem
International SoftModem International SoftModem International SoftModem
Data Transmission Data Transmission Data Transmission Data Transmission Technology speeds: 56,000 Kbps maximum downstream data, controllerless
NOTE: NOTE: NOTE: NOTE: 56 Kbps technology refers to download speeds only and requires
compatible modems at server sites. Other conditions may limit modem
speed. FCC limitations allow a maximum of 53 Kbps during download
transmissions.
Data Speeds Data Speeds Data Speeds Data Speeds (Upload only) 33,600/31,200/28,800/26,400/21,600/19,200/
16,800/14,400/12,000/9,600/7,200/4,800/2,400/1,200/300
Data Standards Data Standards Data Standards Data Standards ITU-T V.90, ITU-T, ITU-T V.34, V.44, V.42, V.42bis21, V.32bis, Bell 212A,
and Bell 103
Fax Speeds Fax Speeds Fax Speeds Fax Speeds 14,400/12,000/9,600/7,200/4,800/2,400/1,200/300 b/s
Fax Mode Capabilities Fax Mode Capabilities Fax Mode Capabilities Fax Mode Capabilities ITU-T T.31 class 1 FAX, V. 17, V.29, V.27ter, and V.21 Channel 2
Error Correction and Error Correction and Error Correction and Error Correction and
Data Compression
Data Compression Data Compression Data Compression
V.44, 42bis, V.42 and MNP2-5
Power Management Power Management Power Management Power Management PCI Bus Power Management Interface Specification (PCI-PM) Revision 1.2,
Appendix A. D0, D3hot, and D3cold. Wake on Ring state when in D3cold. If
the power management event (PME) feature is enabled in D3cold, a modem
can wake the system via WAKE# (WAKEN) or beacon. Meets PCI Express
1.1 standard.
Upgradeability Upgradeability Upgradeability Upgradeability Driver upgradeable for future enhancements
Video Video Video Video ITU-T V.80 video ready interface
QuickSpecs
HP Pro 2000 Business PC HP Pro 2000 Business PC HP Pro 2000 Business PC HP Pro 2000 Business PC
Technical Specifications
DA - 13494 Worldwide — Version 4 — November 29, 2010 Page 19
