Table 6-1. Replaceable Parts (Cont'd)
REFERENCE
-hp-
TQ
DESCRIPTION
MFR.
MFR. PART NO.
DESIGNATOR
PART NO.
A3 (Cont'd)
R40
0684 4721
R: fxd comp 4700 ohms +/-10% 1/4W
01121
CB4721
R41,R42
0698-3382
2
R: fxd met flm 5.49 kilohms +/-1% 1/8W
91637
MF-1/10-32
obd
R43
2100-1770
1
R: var ww 00 ohm +/-10O% 1/2W trimmer
80294
3-365P-E88-101
R44
0698-3223
1
R: fxd met flm 1.24 kilohms +/-1% 1/8W
91637
MF-1/10-32
obd
R45
0684-2231
3
R: fxd comp 22 kilohms +/-10% 1/4W
01121
CB2231
R46*
0684-3921
R: fxd comp 3900 ohms +/-10% 1/4W
01121
CB3921
R47
0684-8211
2
R: fxd comp 820 ohms +/-10% 1/4W
01121
CB8211
R48
0684-2231
R: fxd comp 22 kilohms +/-10% 1/4W
01121
CB2231
R49
0757-4442
3
R: fxd met flm 10 kilohms +/-1% 1/8W
91637
MF-1/10-32
obd
R50
0684-1031
2
R: fxd comp 10 kilohm +/-10% 1/4W
01121
CB1031
R51
0084-8211
R: fxd comp 820 ohm +/-10% 1/4W
01121
CB8211
R52
0767-0280
R: fxd met flm 1 kilohm +/-1% 1/8W
91637
CMF-1/10-32
obd
R53,R54
0684-1211
2
R: fxd comp 120 ohm +/-10% 1/4W
01121
CB1211
R55
0757-0442
R: fxd met flm 10 kilohms +/-1% 1/8W
91637
MF-1/10-32
obd
R56 thru R58
Not assigned
R59
0757-4468
1
R: fxd met flm 130 kilohm +/-1% 1/8W
14674
C4
obd
R60
0684-3331
1
R: fxd comp 33 kilohms +/-106 1/4W
01121
CB3331
R61
0684-1001
3
R: fxd comp 10 ohm +/-10O% 1/4W
01121
CB1001
R62
0684-3921
R: fxd comp 3900 ohms +/-10% 1/4W
01121
CB3921
R63
0684-1031
R: fxd comp 10 kilohms +/-10O 1/4W
01121
CB1031
R64
0684-2231
R: fxd comp 22 kilohms +/-10% 1/4W
01121
CB2231
R65 thru R67
0684-1021
R: fxd comp 1000 ohms +/-10% 1/4W
01121
CB1021
R68
0698-4503
1
R: fxd met flm 66.5 kilohms +/-1% 1/8W
91637
MF-1/10-32
obd
R69
0698-4491
1
R: fxd met flm 30.9 kilohms +/-1% 1/8W
91637
MF-1/10-32
obd
R70,R71
06841001
R: fxd comp 10 ohm +/-10% 1/4W
01121
CBI001
R72*
0684-2701
R: fxd comp 27 ohm +/-10% 1/4W
01121
CB2701
R73
0684-1021
R: fxd comp 1000 ohm +/-10% 1/4W
01121
CB1021
R74*,R75*
0684-8221
2
R: fxd comp 8200 ohm +/-10% 1/4W
01121
CB8221
XA1
1251-1941
1
Connector: PC 6 pin
71785
252-06-30-310
W1
0355-61616
1
Cable
-hp-
A4
03555-66506
1
PC Board Ass'y: filter
-hp-
C1
0140-0177
1
C: fxd mica 400pF +/-1%
72136
RDM15F3C
C2
0180-0291
4
C: fxd Ta elect 1uF +/-10% 35 vdcw
56289
150D105X9035A2-DYS
C3,C4
0160-2130
C: fxd mice 865pF +/-1% 100 vdcw
72136
RDM15F(865)F1C
C5
0140-0203
5
C: fxd mica 30pF +/-5%
72136
RDM15F421F3C
C6
0180-0228
C: fxd elect 22uF +/-10% 15 vdcw
37942
TAS226K015PlC
C7
0140-0163
6
C: fxd mice 4751pF +/-1% 300 vdcw
72136
RDM20F(4751)F3S
C8
0160-3024
4
C: fxd mica 1700pF +/-1% 100 vdcw
72136
RDM19F 72F1S
C9
0140-0203
C: fxd mice 30pF +/-5%
72138
RDM15F421F3C
C10
0160-3024
C: fxd mice 1700pF +/-1% 100 vdcw
72138
RDM19F172F1S
C11
0180-0228
C: fxd Ta elect 22uF +/-10% 15 vdcw
37942
TAS226KOlPlC
C12
0140-0163
C: fxd mica 4751pF +/-1% 300 vdcw
72136
RDM20F(4751)F3S
C13 thru C15
Not assigned
C16
0160-3024
C: fxd mice 1700pF +/-1% 100 vdcw
72136
RDM19F172F1S
C17
0140-0203
C: fxd mica 30pF +/-5%
72136
RDM15F421F3C
C18
0160-3024
C: fxd mica 1700pF +/-1% 100 vdcw
72136
RDM19F172F1S
C19
0180-0228
C: fxd Ta elect 22uF +/-10% 15 vdcw
37942
TAS226KO15P1C
C20,C21
0180-0291
C: fxd Ta elect 1uF +/-10% 35 vdcw
56289
15OD105X9035A2-DYS
C22
Not assigned
C23
0180-0197
C: fxd Ta 2.2uF +/-10% 20 vdcw
56289
150D225X9020A2-DYS
C24
0140-0163
C: fxd mica 4751pF +/-1% 300 vdcw
72136
RDM20F(4751)F3S
C25
0140-0203
C: fxd mice 30pF +I-5%
72136
RDM15F421F3C
C26
0140-0163
C: fxd mice 4751pF +/-1% 300 vdcw
72136
RDM20F(4751)F3S
C27
0180-0228
C: fxd Ta elect 22uF +/-10% 15 vdcw
37942
TAS226K01SPIC
C28,C29
0140-0163
C: fxd mica 4751pF +/-1% 300 vdcw
72136
RDM20F(4751)F3S
C30
0140-0203
C: fxd mice 30pF +/-5%
72136
RDM15F421F3C
6-5
