PERFORMANCE CHECK TEST CARD (Cont'd)
CARRIER 600 BAL
LEVEL ACCURACY CHECK
1kHz to 150kHz
+10dBm Range +10dBm
±
0.5dBm
0dBm Range 0dBm
±
0.5dBm
-10dBm Range -10dBm
±
0.5dBm
-20dBm Range -20dBm
±
0.5dBm
-30dBm Range -30dBm
±
0.5dBm
-40dBm Range -40dBm
±
0.5dBm
-50dBm Range -50dBm
±
0.5dBm
10kHz to 100kHz
+10dBm Range +10dBm ±0.2dBm
0dBm Range 0dBm
±
0.2dBm
-10dBm Range -10dBm ±0.2dBm
-20dBm Range -20dBm ±0.2dBm
-30dBm Range -30dBm
±
0.2dBm
-40dBm Range -40dBm ±0.2dBm
-50dBm Range -50dBm
±
0.2dBm
VF/Nm 600 BAL and 900 BAL
LEVEL ACCURACY CHECK
20Hz to 20kHz 600 ohms 900 ohms
0dBm Range 0dBm
±
0.5dBm
-10dBm Range -10dBm
±
0.5dBm
-20dBm Range -20dBm ±0.5dBm
-30dBm Range -30dBm ±0.5dBm
-40dBm Range -40dBm ±0.5dBm
-50dBm Range -50dBm ±0.5dBm
-60dBm Range -60dBm
±
0.5dBm
-70dBm Range -70dBm ±0.5dBm
-80dBm Range -80dBm ±0.5dBm
40Hz to 1SkHz
0dBm Range 0dBm ±0.2dBm
-10dBm Range -10dBm ±0.2dBm
-20dBm Range -20dBm ±0.2dBm
-30dBm Range -30dBm ±0.2dBm
-40dBm Range -40dBm
±
0.2dBm
-50dBm Range -50dBm ±0.2dBm
-60dBm Range -60dBm
±
0.2dBm
100Hz to 20kHz
+30dBm Range +30dBm 0±0.5dBm
+20dBm Range +20dBm ±0.5dBm
+10dBm Range +l0dBm ±0.5dBm
100Hz to 15kHz
+30dBm Range +30dBm ±0.2dBm
+20dBm Range +20dBm
±
0.2dBm
+10dBm Range +10dBm ±0.2dBm
(2)
