IMAGETEAM™ 2020/4620 System Manual 2 - 21
IT2020-5B Host Escape Commands
Wand Emulation
Wand Emulation Connection
The Wand Emulation Connection bar codes should be used if you want to
change the terminal ID
only, without changing any other imager settings. We
recommend using Wand Emulation Plug & Play bar codes to program your
imager to emulate a wand reader. The Wand Emulation Plug & Play bar codes
change other parameters, in addition to changing the terminal ID. Please refer
to
Wand Emulation Plug & Play on page 2-2 for further information.
In Wand Emulation mode, the imager decodes the bar code then sends data in
the same format as a wand imager. The Code 39 Format converts all
symbologies to Code 39.
The Same Code Format transmits UPC, EAN, Code 128 and Interleaved 2 of 5
without any changes, but converts all other symbologies to Code 39. 2D
symbologies are converted to Code 128.
Command Action
a Indicate as if successful menu change made
b Indicate as if unsuccessful menu change made
1
Illuminate green LED for 135 milliseconds (followed by at least 70 mSecs.
dark time when multiple blinks)
2
Illuminate green LED for two seconds (followed by at least 500 mSecs.
dark time when multiple blinks)
3
Illuminate green LED for five seconds (followed by at least 500 mSecs.
dark time when multiple blinks)
4 One beep at low volume
5 One beep at medium volume
6 One beep at high volume
7 Indicate as successful decode and communication to host.
8 Indicate as unsuccessful decode and communication to host.
