IMAGETEAM™ 2020/4620 System Manual 7 - 5
Codabar Concatenation
Codabar supports symbol concatenation. When you enable concatenation, the
imager looks for a Codabar symbol having a “D” start character, adjacent to a
symbol having a “D” stop character. In this case the two messages are
concatenated into one with the “D” characters omitted.
Default = On.
Select Require to prevent the imager from decoding a single “D” Codabar symbol
without its companion. This selection has no effect on Codabar symbols without
Stop/Start D characters.
Codabar Message Length
Scan the bar codes below to change the message length. Refer to Message
Length Description (page 7-2) for additional information. Minimum and
Maximum lengths = 2-60. Minimum Default = 4, Maximum Default = 60.
A12D D34A
Codabar
Character Stop Start Stop Start
On
* Off
Require
Minimum Message Length
Maximum Message Length
