12 - 24 IMAGETEAM™ 2020/4620 System Manual
Image Ship
*Infinity Filter - Off IMGINF0 8-3
Infinity Filter - On IMGINF1 8-3
*Compensation Off IMGCOR0 8-3
Compensation On IMGCOR1 8-3
*Pixel Depth - 8 bits/pixel
(grayscale)
IMGBPP8 8-3
Pixel Depth - 1 bit/pixel (B&W) IMGBPP1 8-3
*Don’t Sharpen Edges IMGEDG0 8-3
Sharpen Edges (0-23) IMGEDG## 8-3
*File Format - JPEG IMGFMT6 8-3
File Format - KIM IMGFMT0 8-3
File Format - TIFF binary IMGFMT1 8-3
File Format - TIFF binary
group 4, compressed
IMGFMT2 8-3
File Format - TIFF grayscale IMGFMT3 8-3
File Format - Uncompressed
binary
IMGFMT4 8-3
File Format - Uncompressed
grayscale
IMGFMT5 8-3
File Format - BMP IMGFMT8 8-3
*Histogram Stretch Off IMGHIS0 8-4
Histogram Stretch On IMGHIS1 8-4
Invert Image around X axis IMGNVX1 8-4
Invert Image around Y axis IMGNVY1 8-4
Rotate Image 90° right IMGROT1 8-4
Rotate Image 180° right IMGROT2 8-4
Rotate Image 90° left IMGROT3 8-4
JPEG Image Quality (0-100)
*50
IMGJQF### 8-4
*Gamma Correction Off IMGGAM0 8-4
Gamma Correction On (1-255) IMGGAM### 8-4
Image Crop - Left (0-640) *0 IMGWNL### 8-5
Image Crop - Right (0-640)
*639
IMGWNR### 8-5
Image Crop - Top (0-480) *0 IMGWNT### 8-5
Selection
Setting
* Indicates default
Serial
Command
# Indicates a
numeric entry
Page
