Hand Held Products 4620 - Manual (Page 123)

IMAGETEAM™ 2020/4620 System Manual 7 - 19
Telepen Output
Using AIM Telepen Output, the imager reads symbols with start/stop pattern 1
and decodes them as standard full ASCII (start/stop pattern 1). When Original
Telepen Output is selected, the imager reads symbols with start/stop pattern 1
and decodes them as compressed numeric with optional full ASCII (start/stop
pattern 2).
Default = AIM Telepen Output.
Telepen Message Length
Scan the bar codes below to change the message length. Refer to Message
Length Description (page 7-2) for additional information. Minimum and
Maximum lengths = 1-60. Minimum Default = 1, Maximum Default = 60.
UPC-A
UPC-A
Original Telepen Output
* AIM Telepen Output
Minimum Message Length
Maximum Message Length
* On
Off
