12 - 10 IMAGETEAM™ 2020/4620 System Manual
Alarm Sound Type
Base Alarm Type BASORW 3-12
Imager Alarm Type BT_ORW 3-12
Data Accumulation Mode
On BATENA1 3-13
*Off BATENA0 3-13
Output Selections
Beeper - Good Read
Off BEPBEP0 4-1
*On BEPBEP1 4-1
Beeper Volume - Good
Read
Off BEPLVL0 4-1
Low BEPLVL1 4-1
*Medium BEPLVL2 4-1
Beeper Pitch - Good
Read (Frequency)
Low (1600) (min 400Hz) BEPFQ11600 4-2
*Medium (3250) BEPFQ13250 4-2
High (4200) (max 9000Hz) BEPFQ14200 4-2
Beeper Duration - Good
Read *Normal Beep BEPBIP0 4-2
Short Beep BEPBIP1 4-2
LED - Good Read
Off BEPLED0 4-2
*On BEPLED1 4-2
Number of Beeps - Good
Read *1 BEPRPT1 4-3
Range 1 - 9 BEPRPT# 4-3
Good Read Delay
*No Delay DLYGRD0 4-3
Short Delay (500 ms) DLYGRD500 4-3
Medium Delay (1000 ms) DLYGRD1000 4-3
Long Delay (1500 ms) DLYGRD1500 4-3
User-Specified Good
Read Delay
Range 0 - 30,000 ms DLYGRD##### 4-3
Trigger Mode
*Manual/Serial Trigger TRGMOD0 4-4
Read Time-Out
(0 - 300,000 ms) *300,000
TRGSTO#### 4-4
Imager Power Time-Out Timer
(0-7200 seconds) *3600
BT_LPT0 4-5
BT_LPT200 4-5
BT_LPT400 4-5
BT_LPT900 4-5
BT_LPT3600 4-5
BT_LPT7200 4-5
Selection
Setting
* Indicates default
Serial
Command
# Indicates a
numeric entry
