UltraKey Lite Controller Installation and User Guide
Document 800-07422 Rev A 17
08/10
UltraKey Lite Specifications
Table 1-1 UltraKey Lite Specifications
Parameter Value
Power Requirements 10.8 to 13.2 VDC @ 1 Ampere (A) or POE (48 VDC, Class 3)
Connector Types 1×Ethernet (10Base-T, 100Base-TX) RJ45 with LED
1×RS232/422/485 RJ45 with LED
LCD Type: STN, Positive Image
Backlight: Blue-White
Characters: 122×32 Dots
USB Type: A
Version: USB1.1 (For USB PC Keyboard)
Compliance EN55022 for radiated and conducted emissions
Mechanical Dimensions: 408 mm (L) × 215 mm (W) × 105 mm (H)
Gross Weight: 3.2 kg
Cover material: ABS+PC (cool gray)
Environment Operating Temperature: -10 to +55 deg C
Storage Temperature: -40 to +75 deg C
Humidity: 0 to 95% RH (non-condensing)
