Power Supply Power Supply Power Supply Power Supply 1150/500W, Hot Plug 1150/500W, Hot Plug 1150/500W, Hot Plug 1150/500W, Hot Plug
Redundant
Redundant Redundant Redundant (2 standard)
One Redundant Power Supply
(optimized to provide full redundancy at 220 volts)
Input Specifications Input Specifications Input Specifications Input Specifications Normal Line Voltage 100 to 120 VAC/200 to 240 VAC
Range Input Line 90 to 132 VAC/180 to 265 VAC
Frequency Range 47 to 63 Hz
Power Factor 0.95
Input Current 8 A at 100 VAC/10 A at 200 VAC
Inrush Current < 70 A at 132 VAC (cold start)
Holdup Time 20 ms from zero crossing at 120 VAC
General Specifications General Specifications General Specifications General Specifications Full Output Rating To 104° F (40° C) and
5,000 ft (1524 m)
To 89.6° F (32° C) and 10,000 ft (3,048 m)
(derate linearly)
Minimum Load 1 A on 5 V output; 1 A on 12 V output;
0.5 A on 3.3 V output
Ambient Temperature Ambient Temperature Ambient Temperature Ambient Temperature
Range
Range Range Range
Operating 50° to 104° F (10° to 40° C)
Storage -40° to 149° F (-40° to 65° C)
Dielectric Voltage Dielectric Voltage Dielectric Voltage Dielectric Voltage
Withstand
Withstand Withstand Withstand
Input to Output 3,000 VAC/min
Input to Ground 1,500 VAC/min
Input Transient Input Transient Input Transient Input Transient
Susceptibility
Susceptibility Susceptibility Susceptibility
Common and Differential
Mode (superimposed on AC
line) 2,500 V, 1µs, damped sinusold 600 V, 10 µs pulse
Differential Mode 20% step change in AC input voltage
1.44-MB Diskette Drive 1.44-MB Diskette Drive 1.44-MB Diskette Drive 1.44-MB Diskette Drive Size Size Size Size 3.5 in
LED Indicators LED Indicators LED Indicators LED Indicators
(front panel) Green
Read/Write Capacity Read/Write Capacity Read/Write Capacity Read/Write Capacity
per Diskette
per Diskette per Diskette per Diskette (high/low
density)
1.44 MB/720 KB
Drive Supported Drive Supported Drive Supported Drive Supported One
Drive Height Drive Height Drive Height Drive Height 11 mm
Drive Rotation Drive Rotation Drive Rotation Drive Rotation 300 rpm
Transfer Rate Transfer Rate Transfer Rate Transfer Rate Synchronous
(Maximum) (high/low) 500 K/250 K bits/s
Bytes/Sector Bytes/Sector Bytes/Sector Bytes/Sector 512
Sectors/Track Sectors/Track Sectors/Track Sectors/Track (high/low) 18/9
Tracks/Side Tracks/Side Tracks/Side Tracks/Side (high/low) 80/80
Access Times Access Times Access Times Access Times Track-to-Track (high/low) 3/6 ms
Average (high/low) 174/94 ms
Settling Time 15 ms
Latency Average 83/100 ms
Cylinders Cylinders Cylinders Cylinders (high/low) 80/80
Read/Write Heads Read/Write Heads Read/Write Heads Read/Write Heads Two
QuickSpecs
Compaq ProLiant DL760 Compaq ProLiant DL760 Compaq ProLiant DL760 Compaq ProLiant DL760
TechSpecs
DA - 10813 North America — Version 39 — October 17, 2003 Page 35
