UPS Options

SNMP Serial Port Card

192189-B21

NOTE:

NOTE: Supports tower and rack UPS XR models ranging from 1000 – 3000VA.

Six Port Card

192185-B21

NOTE:

NOTE: Supports tower and rack UPS XR models ranging from 1000 – 3000VA.

High to Low Voltage Transformer (250VA)

388643-B21

NOTE:

NOTE: Supports R6000 UPS series only. 2.5 amps @ 125 Volts max output across two NEMA 5-15.

Extended Runtime Module, T1000 XR

218967-B21

NOTE:

NOTE: 2U each, two ERM maximum.

Extended Runtime Module, T1500 XR/T2200 XR

218969-B21

NOTE:

NOTE: 3U each, one ERM maximum.

Extended Runtime Module, R1500 XR

218971-B21

NOTE:

NOTE: 2U each, two ERM maximum.

Extended Runtime Module, R3000 XR

192188-B21

NOTE:

NOTE: 3U each, one ERM maximum.

Extended Runtime Module, R6000

347224-B21

NOTE:

NOTE: 3U each, two ERM maximum.

Extended Runtime Module, R12000 XR, 4U

217800-B21

NOTE:

NOTE: 4U each, two ERM maximum.

SNMP-EN Adapter

347225-B21

NOTE:

NOTE: Supports R6000 UPS series only.

Multi-Server UPS Card

123508-B21

NOTE:

NOTE: Supports R6000 UPS series only.

Scalable UPS Card

123509-B21

NOTE:

NOTE: Supports R6000 UPS series only.

Modular PDUs 1U/0U

(Up to 32 outlets)

NOTE:

NOTE: 1U/0U mounting
brackets shipped with
the unit (optimized for 10000
and 9000 series racks).

HP Modular Power Distribution Units (mPDU), Low Volt Model, 24A (100-127 VAC)

252663-D71

NOTE:

NOTE: This mPDU (252663-D71) may also be used to connect the low volt model of the UPS
R3000 XR.

HP Modular Power Distribution Units (mPDU), High Volt Model, 24A (200-240 VAC)

252663-D72

HP Modular Power Distribution Units (mPDU), High Volt Model, 40A (200-240 VAC)

252663-B21

NOTE:

NOTE: This mPDU (252663-B21), 40A model has a hardwired input.

HP Modular Power Distribution Units (mPDU), High Volt Model, 16A (200-240 VAC)

252663-B24

NOTE:

NOTE: This PDU has a detachable input power cord and allows for adaptability to country specific
power requirements. This model may also be used with the high volt UPSs R3000 XR and R6000 For
North America, need to order cable PN 340653-001.

NOTE:

NOTE: Please see the following Modular Power Distribution Unit (Zero-U/1U Modular PDUs)
QuickSpecs for additional options including shorter jumper cables and country specific power cords:

http://h18000.www1.hp.com/products/quickspecs/11041_na/11041_na.HTML

PDU Options

Third Party Modular PDU Mounting Kit

310777-B21

NOTE:

NOTE: This kit allows you to mount the Modular PDUs in racks other than the 9000/10000 Series
racks (any racks using the standard 19" rail). For more details please refer the Modular PDU
QuickSpecs.

4.5' IEC C 13 to IEC C14 PDU Jumper Cable (1 per pack)

142257-006

4.5' IEC C 13 to IEC C14 PDU Jumper Cable (15 per pack)

142257-007

QuickSpecs

Compaq ProLiant DL760

Options

DA - 10813 North America — Version 39 — October 17, 2003
