Storage Controllers

Smart Array 532 Controller

225338-B21

Smart Array 5302/128 Controller

283552-B21

Smart Array 5304/256 Controller

283551-B21

Smart Array 5312 Controller

238633-B21

Ultra3 Channel Expansion Module for Smart Array 5300 Controller

153507-B21

128-MB Cache Module for Smart Array 5302 Controller

153506-B21

RAID ADG Upgrade for Smart Array 5302

288601-B21

256-MB Battery-Backed Cache Module

254786-B21

NOTE:

NOTE: This 256-MB Battery-Backed Cache Module supports the Smart Array 5300 series controllers,
MSA 1000 and the Smart Array Cluster Storage.

64-bit/66-MHz Single Channel Wide Ultra3 SCSI Adapter

154457-B21

64-bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter

129803-B21

64-Bit/133MHz Dual Channel Ultra320 SCSI Adapter

268351-B21

64-Bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter, Alternate OS

284688-B21

NOTE:

NOTE: Please see the following Controller or SCSI Adapter QuickSpecs for Technical Specifications
such as PCI Bus, PCI Peak Data Transfer Rate, SCSI Protocols supported, SCSI Peak Data Transfer
Rate, Channels, SCSI Ports, Drives supported, Cache, RAID support, and additional information:

http://h18000.www1.hp.com/products/quickspecs/10851_na/10851_na.HTML

(Smart Array 532)

http://h18000.www1.hp.com/products/quickspecs/10640_na/10640_na.HTML

(Smart Array 5300

Series)

http://h18000.www1.hp.com/products/quickspecs/11328_na/11328_na.HTML

(Smart Array 5312)

http://h18000.www1.hp.com/products/quickspecs/10429_na/10429_na.HTML

(SCSI Adapter)

http://h18000.www1.hp.com/products/quickspecs/11555_na/11555_na.HTML

(U320 Adapter)

Communications

Compaq NC3123 Fast Ethernet NIC PCI 10/100 WOL

174830-B21

Compaq NC3134 Fast Ethernet NIC 64 PCI Dual Port 10/100

138603-B21

Compaq NC3135 Fast Ethernet Upgrade Module

138604-B21

Compaq NC6132 Gigabit Module 1000 SX Upgrade Module for NC3134 and NC3131

338456-B23

Compaq NC6133 Gigabit Module 1000LX Upgrade Module for NC3134 and NC3131

338456-B24

Compaq NC3133 Fast Ethernet Module 100FX Upgrade Module for NC3134 and NC3131

338456-B25

Compaq NC6136 Gigabit Server Adapter, 64-bit/66-MHz, PCI, 1000 SX

203539-B21

Compaq NC7131 Gigabit Server Adapter, 64-bit/66-MHz, PCI, 10/100/1000-T

158575-B21

Compaq NC7132 10/100/1000-T Upgrade Module for NC3134 and NC3131

153543-B21

Compaq NC7770 PCI-X Gigabit Server Adapter

244948-B21

Redundant Options

1150/500-Watt Hot Plug N 1 redundant power supply

401231-001

NOTE:

NOTE: A maximum of two power supplies are supported by the ProLiant DL760.

Management Options

Remote Insight Lights-Out Edition II

227251-001

Security

HP/Atalla AXL600L SSL Accelerator Card for ProLiant Servers

524545-B21

Compaq AXL300 Accelerator PCI Card (HW SSL Encryption) for ProLiant Servers

227933-B21

QuickSpecs

Compaq ProLiant DL760

Options

DA - 10813 North America — Version 39 — October 17, 2003
