External Storage External Storage External Storage External Storage
Quantity Quantity Quantity Quantity
Supported
Supported Supported Supported
Position Position Position Position
Supported
Supported Supported Supported Controller Controller Controller Controller
StorageWorks Enclosure 4300
Family
(supports Ultra2/Ultra3 drives)
Up to 44 External Smart Array 532 Controller
Smart Array 5302/128 Controller
Smart Array 5304/256 Controller
Smart Array 5312 Controller
64-bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter
64-bit/66-MHz Single Channel Wide Ultra3 SCSI Adapter
64-Bit/133MHz Dual Channel Ultra320 SCSI Adapter
MSA 1000 Please see the MSA
1000 QuickSpecs
below to determine
configuration
requirements External Please see the MSA 1000 QuickSpecs (URL below) for the latest list of supported
HBA’s
MSA 1000: http://h18000.www1.hp.com/products/quickspecs/11033_na/11033_na.HTML
Maximum Storage Capacity Maximum Storage Capacity Maximum Storage Capacity Maximum Storage Capacity – (StorageWorks Enclosure SCSI Attached)
Internal 587.2 GB (4 x 146.8-GB Ultra320 1
″
Drives)
External 90.428 TB hot plug SCSI storage (44 x (14 x 146.8-GB Ultra320 1
″
Drives))
Total 91.016 TB
QuickSpecs
Compaq ProLiant DL760 Compaq ProLiant DL760 Compaq ProLiant DL760 Compaq ProLiant DL760
Storage
DA - 10813 North America — Version 39 — October 17, 2003 Page 32
