Pre-existing SMS

Pre-existing SMS
Customers

Customers

Some customers may have an existing rp2470 or A500 SMS that required a separate console device. Typically a Unix
workstation or PC was configured in these environments. These customers may continue to use their existing SMS (with the
appropriate software upgrade) along with their existing console device to access the new PA-8800 Superdome. A
Superdome console must meet the following requirements:

HP Workstation running HP-UX 11.0 or 11i v1
PC running Windows NT, XP, 2000
C1099A terminal server (limited functionality due to text mode only operation)
10Base-T Ethernet connection or an RS-232 port or both.
X windows emulator for console access on the PC (i.e., Reflection for HP with NS/VT).

Option 006 and 007 Specifics

Customer-Provided Part

PDCA Product Number

Attached Power Cord

Attached Plug

In-Line Connector

Panel-Mount Receptacle

A5800A Option 006

OLFLEX 190 (PN 600804),
four conductor, 6-AWG (16-
mm

), 600-Volt, 60-Amp, 90-

degree C, UL, and CSA
approved, conforms to CE
directives GN/YW ground
wire.

Mennekes ME 460P9 3-phase,
4-wire, 60-Amp, 250-Volt, UL
approved. Color blue, IEC
309-1, IEC 309-1, grounded
at 3:00

Mennekes ME 460C9 3-
phase, 4-wire, 60-amp, 250-
Volt, UL approved. Color
blue, IEC 309-1, IEC 309-1,
grounded at 9:00.

Mennekes ME 460R9 3-phase,
4-wire, 60-amp, 250-Volt, UL
approved. Color blue, IEC
309-1, IEC 309-1, grounded
at 9:00.

A5800A Option 007

Five conductors, 10-AWG (6-
mm

), 450/475-Volt, 32-

Amp, European wire
cordage, GN/YW ground wire.

Mennekes ME 532P6-14 3-
phase, 5-wire, 32-Amp,
450/475-volt, VDE certified,
color red, IEC 309-1, IEC
309- 2, grounded at 6:00.

Mennekes ME 532C6-16 3-
phase, 5-wire, 32-Amp,
450/475-Volt, VDE certified,
color red, IEC 309-1, IEC
309-2, grounded at 6:00.

Mennekes ME532R6-1276 3-
phase, 5-wire, 32-Amp,
450/475-Volt, VDE certified,
color red, IEC 309-1, IEC
309-2, grounded at 6:00.

a. In-line connector is available from HP by purchasing A6440A, Option 401.
b. Panel-mount receptacles must be purchased by the customer from a local Mennekes supplier.
c. In-line connector is available from HP by purchasing A6440A, Option 501.

NOTE:

NOTE: A qualified electrician must wire the PDCA in-line connector to site power using copper wire and in compliance with all local codes.

Input Requirements

Reference the Site Preparation Guide for detailed power configuration requirements.

Requirements

Value

Conditions/Comments

Nominal Input Voltage (VAC rms)

200/208/220/230/240

Input Voltage Range (VAC rms)

200-240

Auto selecting. Measure at input terminals.

Frequency Range (Hz)

50/60

Number of Phases

3-phase 5-wire with power cord;
3-phase 4-wire with power cord

Maximum Input Current (A rms), 3-Phase 5-wire

3-phase source with a source voltage of 220 VAC
measured phase to neutral

Maximum Input Current (A rms), 3-Phase 4-wire

3-phase source with a source voltage of either 208
VAC or 230 VAC measured phase-to-phase

Maximum Inrush Current (A peak)

Circuit Breaker Rating (A), 3-Phase 5-wire

25 A

Per phase

Circuit Breaker Rating (A), 3-Phase 4-wire

45 A

Per phase

Power Factor Correction

0.95 minimum

Ground Leakage Current (mA)

>3.5 mA, with 6 BPSs installed

Warning label applied to the PDCA at the AC
Mains input

QuickSpecs

HP 9000 Superdome Servers

(PA-8600, PA-8700 and PA-8800)

System Management Features

DA - 11721 North America — Version 13 — April 1, 2005
