Specifications 40
Specifications
UPS physical specifications
Parameter Value
Height
8.9 cm (3.5 in)
Depth
48.3 cm (19 in)
Width
44.5 cm (17.5 in)
Weight
29 kg (64 lb)
ERM physical specifications
Parameter Value
Height
8.9 cm (3.5 in)
Depth
34.3 cm (13.5 in)
Width
44.5 cm (17.5 in)
Weight
28.6 kg (63 lb)
UPS input specifications
NOTE:
An asterisk (*) indicates the default setting.
UPS model
Utility voltage
frequency (Hz)
Available settings
utility voltage (VAC)
Branch circuit
rating (A)
Line cord
R/T2200
NA/JPN/TWN
50/60
100, 110, 120*
20
Nondetachable power
cord with NEMA 5-20
plug
R/T2200 INTL
50/60
220, 230*, 240
15
Detachable power cord
with IEC-320-C20 plug
UPS output specifications
UPS model
Output receptacles
Maximum current
R/T2200
NA/JPN/TWN
4 x NEMA 5-15R, 4 x NEMA 5-
15/20R
18.3 A
R/T2200 INTL
8 x IEC-320-C13
9.5 A
