HP Z400 - Manual (Page 44)

HP Thin USB Powered
Speakers Frequency Response (-
3dB, 24-bit/96kHz input) FO to 20kHz
Dimensions Speakers: 5.72 x 3.74 x 0.96 in (14.52 x 9.50 x 2.45 cm) per speaker
On/Off/Volume Controls Right side of right speaker
Power LED Front of right speaker (green)
Watts 2/3 watt (normal/maximum)
Net weight 0.68 lbs (0.31kg)
Environmental (all
conditions non-condensing) Temperature (operating): 14° to 104° F (-10° to 40° C)
Relative Humidity
(operating): 40% to 90%
Speaker cable length Input cord: 5.91 ft (1800mm±35mm)
L-channel cord: 3.28 ft (1000mm±35mm)
USB cord: 5.91 ft (1800mm±35mm)
Color HP Carbonite
Kit Contents One pair of HP Thin USB Powered Speakers with attached audio signal and
USB power cables for connecting to your PC
HP Warranty documentation
SoundBlaster (Creative
Labs) X-Fi Titanium PCIe
Audio Card 24-bit Analog-to-Digital
conversion of analog
inputs 96kHz sample rate
24-bit Digital-to-Analog
conversion of digital
sources 96kHz to analog 7:1 speaker output
24-bit Digital-to-Analog
conversion of stereo
digital sources 8, 11.025, 16, 22.05, 24, 32, 44.1, 48 and 96kHz
16-bit to 24-bit recording
sampling rates 16-bit/44.1kHz, 16-bit/48kHz, 24-bit/44.1kHz, 24-bit/48kHz and 24-
bit/96kHz with direct monitoring
Enhanced SoundFont
support Up to 24-bit resolution
Signal-to-Noise Ratio
(2okHz Low-pass filter, A-
Weighted) 109dB
Total Harmonic Distortion
+ Noise at 1kHz (20kHz
Low-pass filter) .004%
Frequency Response (-
3dB, 24-bit/96kHz input) 10Hz to 46kHz
Frequency Response (-
3dB, 24-bit/192kHz
input) 10Hz to 46kHz
Speaker and Headphone
connections Stereo to 7.1 (Line Out via three 3.5mm mini jacks)
Flexijack Line In/ Microphone In/Optical Out via shared 3.5mm mini jack
Front Panel Header Intel HD Audio Compatible (2x5 pin)
QuickSpecs
HP Z400 Workstation
Technical Specifications - Multimedia and Audio Devices
DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009 Page 44
