HP Z400 - Manual (Page 3)

Color Jack Black/Alloy metallic
Convertibility Yes. 5.25" drives rotate for Minitower or Desktop orientation.
Expansion Slots (see
system board section for
more details) 2 PCI slots (full-height, full-length)
1 PCI Express Gen2 slot x8 mechanical/x4 electrical
1 PCI Express Gen1 slot x8 mechanical/x4 electrical
2 PCI Express x16 Gen2 slots (one dedicated for graphics)
Expansion Bays (see
storage section for more
details) 2 internal 3.5" bays
3 external 5.25" bays
NOTE: Third external 5.25" bay is not full depth; maximum depth 170 mm (6.7 inches)
Front I/O 2 USB 2.0, 1 IEEE 1394 (requires optional PCI card to function), 1 audio out, and 1 microphone.
Rear I/O 6 USB 2.0, 1 optional serial port, 2 PS/2, RJ-45 (NIC), 1 audio line in, 1 audio line out, 1 microphone
in; audio ports can be retasked to function as line in, line out, microphone, or headphone.
Interfaces Supported 22-in-1 Media Card Reader (optional)
Chassis Dimensions (W x
D x H) Standard minitower orientation: 6.6 x 17.9 x 17.7 in (16.79 x 45.53 x 45.02 cm)
Converted desktop orientation: 6.6 x 17.9 x 17.7 in (16.79 x 45.53 x 45.02 cm)
Weight Exact weights depend upon configuration
Minimum: 29.8 lbs (13.5 kg)
Standard: 33.2 lbs (15.1 kg)
Maximum: 43.2 lbs (19.6 kg)
Temperature Operating: 40° to 95°F (5° to 35°C)
Non-operating –40° to 140° F (–40° to 60° C)
Humidity Operating: 8% to 85%
Non-operating 8% to 90%
Maximum Altitude (non-
pressurized) Operating: 10,000 feet; 3,000 m
Non-operating 30,000 feet; 9,100 m
Power Supply 475 watts wide-ranging, active Power Factor Correction, 85% Efficient
QuickSpecs
HP Z400 Workstation
Overview
DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009 Page 3
