Power Supply Requires T15 Torx or flat blade screwdriver
PCI Card Retention Yes, rear (all), middle (none), front (full-length cards with extender)
Flash ROM Yes
Diagnostic Power Switch
LED on board Yes
Clear Password Jumper Yes
Clear CMOS Button Yes
CMOS Battery Holder for
easy Replacement Yes
DIMM Connectors for
easy Upgrade Yes
HP ProtectTools Security
Manager Yes - Not supported on Microsoft XP x64 or Linux
BIOS
BIOS 32-bit Services Standard BIOS 32-bit Service Directory Proposal v0.4
PCI 3.0 Support Full BIOS support for PCI Express through industry standard interfaces.
ATAPI ATAPI Removable Media Device BIOS Specification Version 1.0.
BBS BIOS Boot Specification v1.01.
WMI Support WMI is Microsoft's implementation of Web-Based Enterprise Management (WBEM) for Windows. WMI
is fully compliant with the Distributed Management Task Force (DMTF) Common Information Model (CIM)
and WBEM specifications.
BIOS Boot Spec 1.01+ Provides more control over how and from what devices the workstation will boot.
BIOS Power On Users can define a specific date and time for the system to power on.
ROM Based Computer
Setup Utility (F10) Review and customize system configuration settings controlled by the BIOS.
System/Emergency ROM
Flash Recovery with Video Recovers system BIOS in corrupted Flash ROM.
Replicated Setup Saves BIOS settings to diskette or USB flash device in human readable file. Repset.exe utility can then
replicate these settings on machines being deployed without entering Computer Configuration Utility (F10
Setup).
SMBIOS System Management BIOS 2.6, for system management information.
Boot Control Disables the ability to boot from removable media on supported devices.
Memory Change Alert Alerts management console if memory is removed or changed.
Thermal Alert Monitors the temperature state within the chassis. Three modes:
NORMAL - normal temperature ranges
ALERTED - excessive temperatures are detected. Raises a flag so action can be taken to avoid
shutdown or provide for a smoother system shutdown
SHUTDOWN - excessive temperatures are encountered. Automatically shuts down the computer
without warning before hardware component damage occurs
Remote ROM Flash Provides secure, fail-safe ROM image management from a central network console.
ACPI (Advanced
Configuration and Power
Management Interface) Allows the system to enter and resume from low power modes (sleep states).]
Enables an operating system to control system power consumption based on the dynamic
workload.
Makes it possible to place individual cards and peripherals in a low-power or powered-off state
QuickSpecs
HP Z400 Workstation
System Technical Specifications
DA - 13276 Worldwide QuickSpecs — Version 1 — 3.30.2009 Page 22
