2 overview – HP LH 3r User Manual
Page 9

5
2 Overview
The steps required to install the NetServer in the rack are summarized below:
NOTE
This is only a summary; detailed instructions are provided on the
following pages.
•
Measure and mark the appropriate holes on all four rack columns
•
Install one bar nut on each of the four rack columns
•
Insert two rack nuts on each of the two front columns only
•
Attach the slides to the columns
•
Extend the slides
•
Remove power supply modules and hot-swap drives from the NetServer
•
Lift the NetServer onto the slides
•
Secure the NetServer to the slides
•
Remove the lifting handles from the NetServer
•
Install the power supply modules and hot-swap drives in the NetServer
•
Push the NetServer back into the chassis
•
Install the recessed mounting brackets on the two front columns only
