Chapter 3 Installation
11
Push In and Up
Figure 3-4. Mounting a Slide to a Column
Installing the NetServer
1. Extend the slides until you hear a click, indicating they are fully extended
in the locked-out position. Note that the slides do not come apart (see
Figure 3-3).
WARNING To prevent the rack from tipping over, be sure that the
stabilizing, anti-tip feature is installed on this rack enclosure
(see Figure 1-2).
2. Before you lift the NetServer, remove the power supply modules and the
hot-swap hard disk drives to reduce the weight.
WARNING This NetServer weighs up to 160 pounds (73 kg.) when fully
configured. Remove all power supply modules and hot-swap
hard disk drives before lifting the NetServer.
Use two people when moving the NetServer or lifting it into
the rack.
