Chapter 2 Overview
6
Terms used in this document are defined in the table below.
Term Definition
Bar nut Short, threaded bar used behind slide mounting flanges.
Used in place of individual nuts to mate with slide
mounting screws.
Rack nut Single nut designed to clip behind the rack column and
accept a screw through the hole in the column.
Slide Extendible side bracket which is attached to the rack
chassis columns on which the NetServer is mounted.
Consists of stationary component, and an extendible
member (see Figure 3-3). Allows access to the NetServer
after it is installed in the rack chassis.
Slide mounting flange Mounting flange located at either end of the slide (see
Figure 3-3).
Rack (rack chassis,
rack enclosure) The equipment enclosure in which the NetServer will be
installed.
Recessed mounting
brackets Two brackets (one tall, one short) that attach to the front of
the NetServer and the front rack columns to hold the
NetServer in the closed position.
EIA unit Industry standard measurement (1.75 inches / 44.45 mm),
consisting of four vertical mounting holes in a rack
column.
