Software and configuration utilities 42

USB support and functionality

USB support

HP provides both standard USB 2.0 support and legacy USB 2.0 support. Standard support is provided

by the OS through the appropriate USB device drivers. Before the OS loads, HP provides support for USB

devices through legacy USB support, which is enabled by default in the system ROM.
Legacy USB support provides USB functionality in environments where USB support is not available
normally. Specifically, HP provides legacy USB functionality for the following:

POST

RBSU

Diagnostics

DOS

Operating environments which do not provide native USB support

Internal USB functionality

An internal USB connector is available for use with security key devices and USB drive keys. This solution
provides for use of a permanent USB key installed in the internal connector, avoiding issues of clearance

on the front of the rack and physical access to secure data.

Diagnostic tools

HP Insight Diagnostics

HP Insight Diagnostics is a proactive server blade management tool, available in both offline and online

versions, that provides diagnostics and troubleshooting capabilities to assist IT administrators who verify
server blade installations, troubleshoot problems, and perform repair validation.
HP Insight Diagnostics Offline Edition performs various in-depth system and component testing while the

OS is not running. To run this utility, launch the SmartStart CD.
HP Insight Diagnostics Online Edition is a web-based application that captures system configuration and
other related data needed for effective server blade management. Available in Microsoft® Windows®

and Linux versions, the utility helps to ensure proper system operation.
For more information or to download the utility, refer to the HP website

(

http://www.hp.com/servers/diags

).

HP Insight Diagnostics survey functionality

HP Insight Diagnostics (on page

42

) provides survey functionality that gathers critical hardware and

software information on ProLiant server blades.
This functionality supports operating systems that may not be supported by the server blade. For operating

systems supported by the server blade, see the HP website (

http://www.hp.com/go/supportos

).

If a significant change occurs between data-gathering intervals, the survey function marks the previous

information and overwrites the survey data files to reflect the latest changes in the configuration.
