Page 33
Service Parts
Super Mag Stoker
Beginning Manufacturing Date: July 2009
Ending Manufacturing Date: Active
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement
parts for your appliance please provide model number and serial number. All parts listed
in this manual may be ordered from an authorized dealer.
Stocked
at Depot
ITEM
Description
COMMENTS
PART NUMBER
31
1/4"-20 x 1/2" Alloy Steel Black Oxide Button Head Cap Screw
Pkg of 100
3-30-3015-100
Y
32
6 mm Spring Washer
Pkg of 25
3-31-08558-25
33
Air Grill
2-00-02726L
34
Standard Firebrick 9" x 4-1/2" x 1-1/4"
Pkg of 7
1-00-900450125
Y
35
Angle Cut Brick - Set of cut brick
2-00-00688
Y
36
Side Panel
Qty. 2 req.
2-00-02722B
37
Body Weldment
1-89-02700W
38
Duct Cover Weldment
1-10-02740W
39
Hopper Assembly
1-10-02733-1A
Y
40
ESP Probe
3-20-02778
Y
41
#8-18 x 3/4" Hex Washer Head TEKS Drill and Tap
Pkg of 100
3-30-5003-100
Y
42
1/4-20x5/8" Hex Washer Slot T23 Zinc Thread Cutting Screw
Pkg of 50
3-30-1111-50
Y
3/8"-16 x 1/4" Alloy Steel Black Oxide Cup Point SSS
Pkg of 25
3-30-2014-25
Y
Air Grill
Brushed Stainless
3-43-02726-7
Ash Door Tile Frame
Brushed Stainless
3-43-02729-7
Ball Plunger, 5/16 x 1/2
Pkg of 3
3-31-5500-3
Ball Spring Bracket
2-00-06714
Brick, Full skid
414 Pcs
3-40-900450-414
Door Hinge w/Pin
Qty 2 req
3-00-773813
Door Trim
Brushed Stainless
3-43-06931-7
D-Shape Knob/Shaft
25 Sets
1-00-015605
Y
Fem Disc- Fully Ins
Pkg of 25
1-00-00959
Y
Front Door Handle & Bolt
1-00-00247
Y
Front Door Latch
3-00-249119P
Y
Gasket Glue, 32 oz
3-42-4583
Gasket, 3/8 RD HD
5 Ft
1-00-43375
Y
Glass clips w/Hardware
Set of 4
2-00-05202-4
Y
Ground Harness
3-20-02776
Label, Control Board
3-90-08646
Labels, Caution & Danger
10 Ea
1-00-200408541
Load Door
4-00-06920P
Load Door Latch Hardware
1-00-06903
Power Cords w/Ends
3-20-39685
Y
Room Sensor
3-20-00906
Y
Thermostat Extension
3-20-00607
Y
Thermostat Probe Extension
3-20-72225
Y
Touch Up Paint, Aerosol
Black
3-42-1990
Wiring Harness
3-20-02775
Additional Service Parts on following page
