Super-Magnum Coal Stoker Stove
Do Not Burn Wet Coal! 3-90-02702R6_03/13
3. Fines Tray Emptying
• Frequency: Weekly
• By: User
Wear Gloves To Perform
Fines are small dust-like particles which fall from the feed
system during operation. Depending on the fuel being used,
this tray may need emptied more frequently. Open the left
rear access door and remove the fines tray by sliding it out.
If the tray over-flowed, vacuum the fines tray area prior to
re-inserting the tray. These fines can be disposed of with
your household garbage.
Fines tray
(removed)
4. Door Glass
• Frequency: As needed / Weekly
• By: User
Whenever the view of the fire is obstructed, or weekly,
clean the glass using a soft cloth dampened with standard
household glass cleaner.
Never spray glass cleaner directly onto hot glass. Apply
the cleaner to the cloth then wipe the glass.
Fly-ash allowed to accumulate on the glass may lead to
permanent fogging or "crazing" of the glass.
Inspect the glass and sealing gasket. Replace gasket as
needed. Do not operate the stove with a broken glass.
Replacement glass, which is ceramic glass, should be
obtained through your Harman dealer.
To replace a broken glass; first be sure to carefully remove
the broken glass and any remaining shards or pieces. With
the door laying on a flat surface, lay the gasketted glass
panel onto the door and be sure it is properly fitted into the
channel. Lay the glass retainer clips in place near each
corner, and secure them using the 3/8" screws. Be sure to
tighten each screw equally so you don't create a pressure
point on the glass.
Glass Retainer
screws
Glass Panel
Gasket
Glass Retainers
Door Frame
Warning: Do not abuse glass by striking or slamming
the door closed. This type of breakage is not covered
by the product warranty.
