About the DCS 645
49 Contents Back Next Index
Status Screen
The Status screen provides a quick display of the
DCS 645’s current setup.
Displaying the Status screen
✔ Highlight the Status screen icon (page 46) .
The Status screen appears with the following
information:
a - Estimate of the number of images that can be
captured to the installed CF Card (page 68)
b - Fill level (in color) indicates the approximate
amount of space available on the active card
c - ISO setting
d - Name of active folder and the number of
images in that folder
e - DCS 645 Battery level
f - Current image format - full frame, horizontal,
or vertical (page 91)
g - Appears if the DCS 645 is connected to a
computer (page 84) and flashes if the DCS
Capture Studio or DCS Camera Manager
software is not running
h - Number of the currently selected image
(page 109)
a
b
c
d
e
g
h
f
