Connecting to a Video Camera
The following illustration shows you how to connect the TV to a
camcorder. Actual connections may vary according to the make and
model of the device. Refer to the user’s manual included with the
camcorder for more detailed instructions.
AV2
LINE OUT
S-VIDEO
R
AV1
L
VIDEO
DC-IN
ANT
AV2
LINE OUT
S-VIDEO
R
AV1
L
VIDEO
DC-IN
ANT
WB
S
B
R
W
Y
4-IN-1 cable
S-Video
Cables and connectors are color-
coded (black, red, white, yellow).
AV2
connector
Note: When connecting the S-Video connec-
tor and AV connectors at the same time, the
priority is given to the S-Video connector.
AV connctors
