Havis-Shields K9/Prisoner Transport Unit KK-K9-C20-K-PT User Manual
Page 2
KK-K9-C20-K-PT_INST_10-07
Always!
Read all instructions before installing any Havis-Shields Equipment Corp products
Disconnect the vehicle battery. Removing seat bolts on some vehicles may give the vehicles
computer a false reading, causing a warning light on the instrument cluster. This requires the
vehicles’ computer to be reset with a vehicle diagnostics tool.
Check for obstructions (Wire, brake lines, fuel tank, etc.) before drilling any holes!
Use only hardware provided with install kit.
For product support, visit the Install Instructions Section of our website at
http://havis.com/Installation/Installation.html
or call 1-
800-524-9900 and ask for technical support.
***CAUTION!!! ON PASSENGER SIDE REAR, UNDER THE VEHILCE, ARE
REFRIGERANT LINES THAT MAY LINE UP WITH REAR PARTITION FILLER PANEL
DO NOT DRILL THROUGH VEHILCE IN THIS LOCATION
K9
Assembly
Front prisoner
filler panel &
Front prisoner
seal panel
Upper prisoner
filler panel
K9 tunnel
assembly
Rear prisoner
filler panel
Passenger-side “B” pillar
mounting brackets
Two “L” Brackets
See photos
Driver-side floor
mounting bracket
Passenger-side floor
mounting bracket
Lower prisoner
filler panel
