System Unit Dimensions
(H x W x D)
(with bezel) 1.70 x 17.64 x 27.59 in (4.32 x 44.80 x 69.95 cm)
Weight
(approximate) Maximum
(all hard drives, power
supplies, and processors
installed) 32.08 lb (14.55 kg)
Minimum
(one hard drive, power
supply, and processor
installed) 27.4 lb (12.43 kg)
Input Requirements
(per 500W power
supply) Rated Line Voltage 100 to 127 VAC
200 to 240 VAC
Rated Input Current 4.99A (at 115 VAC), 2.46A (at 230 VAC)
Rated Input Frequency 47 to 63 Hz
Rated Input Power 574W (at 100 VAC)
573W (at 200 VAC)
BTU Rating Maximum 500W 1700 BTU / hr (at 100
VAC)
1700 BTU/hr (at 200
VAC)
Power Specifications To review typical system power ratings use the Power Advisor which is
available via the online tool located at URL:
www.hp.com/go/hppoweradvisor
- Click on the system of interest. Example: DL165 G7
- Follow the instructions of the next screens.
Power Supply Output
(per power supply) Rated Steady-State
Power 500 Watts (at 100 VAC),
500 Watts (at 200 VAC)
Maximum Peak Power 500 Watts (at 100 VAC),
500 Watts (at 200 VAC)
Optional High Efficiency Power Supply Specifications
Input Requirements
(per power supply) Rated Line Voltage 90-110 VAC,
108-132 VAC
180-264VAC
Rated Input Current 7.4 A (at 115 VAC),
3.6 A (at 230 VAC)
Rated Input Frequency 47 to 63 Hz
Rated Input Power 846 W (at 115 VAC),
822W (at 230 VAC)
BTU Rating Maximum 750 W 2550 BTU/hr (at 100
VAC),
2550 BTU/hr (at 200
VAC)
Power Specifications To review typical system power ratings use the Power Advisor which is
available via the online tool located at URL:
www.hp.com/go/proliant-
energy-efficient
- Click on the system of interest. Example: DL165 G7
- Follow the instructions of the next screens.
Power Supply Output
(per power supply) Rated Steady-State
Power 750 W (at 100 VAC),
750W (at 200 VAC)
Maximum Peak Power 750 W (at 100 VAC),
750 W (at 200 VAC)
QuickSpecs
HP ProLiant DL165 Generation 7
Technical Specifications
DA - 13602 Worldwide QuickSpecs — Version 2 — 4.2.2010 Page 35
