DIMM Type Registered DIMMS (RDIMMs)
Unbuffered with ECC
DIMMs (UDIMMs)
DIMM Rank Single Rank Dual Rank (2R)
Quad Rank
(4R) Dual Rank (2R)
DIMM Capacity 4GB 2GB 8GB 16GB 2GB 4GB
DIMM Native Speed (MHz) 1333 1333 1333 1066 1333 1333
Voltage LV/Reg Reg LV/Reg Reg Reg Reg
SLOTS THAT CAN BE POPULATED
24 slot servers 24 24 24 8 16 16
MAXIMUM CAPACITY (GB)
24 slot servers 96 48 192 256 * 32 64
POPULATED DIMM SPEED (MHz)
1 DIMM Per Channel 1333 1333 1333 1066 1333 1333
2 DIMM Per Channel 1333 1333 1333 n/a 1333 1333
3 DIMM Per Channel 1333 1066 1066 n/a n/a n/a
* This capacity is achieved by loading 1 16GB in center socket and remaining sockets with 8GB DIMMs.
DIMM slot and configuration diagrams
Basic memory slot & population diagram
Population order; start with "A" first, "B" second, "C" third, etc.
24 DIMM SLOTS (12 per CPU node)
CPU1 CPU2
slot # population order slot # population order
Chnl 1 1 A 1 A Chnl 1
2 I 2 I
3 E 3 E
Chnl 2 4 C 4 C Chnl 2
5 K 5 K
6 G 6 G
Chnl 3 7 B 7 B Chnl 3
8 J 8 J
9 F 9 F
Chnl 4 10 D 10 D Chnl 4
11 L 11 L
12 H 12 H
NOTE: Capacity references are rounded to the common Gigabyte values.
2GB = 2048MB
4GB = 4096MB
8GB = 8192MB
16GB = 16384MB
QuickSpecs
HP ProLiant DL165 Generation 7
Memory
DA - 13602 Worldwide QuickSpecs — Version 2 — 4.2.2010 Page 27
