QuickSpecs
HP Compaq dx2300 Microtower Business PC
System Details
EMEA edited August 29, 2007 –details may vary by region Page 9
1 x serial header to support optional second serial port
Board Size Micro-ATX, PCB Size: 9.6 x 9.0 in (24.38 x 22.86 cm)
4-layer PCB with green color
Additional Features Bootable without keyboard, mouse or monitor
Keyboard/mouse/USB wake up
Support S1, S3, S4 and S5
ACPI status
Hardware monitor capability
CPU fan speed control
Hardware Highlights PCI interfaces Intel PRO/100 VE
Network Connection Features
10-Mbps and 100-Mbps operation
Hardware Highlights PCI Express interface
Network Interface
Intel PRO/1000 PT
Gigabit PCIe
Adapter
Features 10-Mbps, 100-Mbps and 1000-Mbps
operation
Wireless Wireless A+G PCI Card (full height bracket)
Power Supply
• ATX Power Supply – Passive PFC/non-PFC with a 115v/230v line switch
• Passive Power Factor Correction (PFC) – with line switch set to 230V – No PFC in 115V
line switch position
• 90 to 140VAC, or 180 to 264VAC operating voltage range
• 100 to 127VAC, or 200 to 240VAC rated voltage range
•
50–60 Hz rated line frequency
• 47–63 Hz operating line frequency range
•
250 watt maximum rated power
• 80-mm power supply fan – variable speed for optimum acoustics
Power Conservation
‘Energy Saver‘ APM 1.2 support
Screen blanking
Hard drive 'Idle' mode
System Idle mode
~2 watt power consumption in ES mode – suspend to RAM (S3) (instantly available PC)
Processor/Cache memory power-down (S3)
• Values are subject to change without notification and are for reference only.
• Performance of system, options, and ancillary equipment will vary depending on the
system configuration.
• Levels presented do not account for non-HP/Compaq installed hardware.
System
Environmental Specs
Ambient Air
Temperature Operating 50° to 95°F (10° to 35°C) at sea level with
an altitude de-rating of 1.0°C per every
