QuickSpecs
HP Compaq dx2300 Microtower Business PC
Technical Specifications - Input Devices
EMEA edited August 29, 2007 –details may vary by region Page 25
Ergonomic
compliance ANSI HFS 100, ISO 9241-4, and TUVGS
Scroll Wheel 8 mm
Maximum Rotation
Speed 30 mm/s
Switch Type Light force micro-switch
Switch Life 1 million operations
Mechanical Life Minimum 200,000 revolutions
Operating
Temperature 50° to 122° F (10° to 50° C)
Non-operating
Temperature -22° to 140° F (-30° to 60° C)
Operating Humidity 10% to 90% (non condensing at ambient)
Non-operating
Humidity 20% to 80% (non condensing at ambient)
Operating Shock 40 g, 6 surfaces
Non-operating
Shock 80 g, 6 surfaces
Operating Vibration 2 g peak acceleration
Environmental
Non-operating
Vibration 4 g peak acceleration
Operating Voltage + 5VDC ± 10%
Power Consumption 15mA
System Consumption PS/2 mini-din connector
ESD CE level 4, 15 kV air discharge
EMI-RFI Conforms to FCC rules for a Class B
computing device
Electrical
PC98 Functionally compliant
Resolution 400 ± 20% DPI
Tracking Speed 10 in/s maximum
Acceleration 100 in/s
Switch Actuation 85 g nominal peak force
Switch Life 1,000,000 operations (using Hasco
modified tester)
Cable Length 2 m
Mechanical
PC98-99 Mechanically compliant
HP 2-Button Scroll
Mouse (PS/2)
Regulatory
Approvals UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI, BCIQ, C-Tick
