HP DX2300 - Manual (Page 18)

QuickSpecs
HP Compaq dx2300 Microtower Business PC
Technical Specifications - Communications
EMEA edited August 29, 2007 –details may vary by region Page 18
Power consumption Tx/Rx peak 560/250mA @ 3.3V (max.)
Output power
(approximately) 15 dBM ±2dB
Receive sensitivity -90dBm at 11 Mbps (typical)
Data transfer rate Standard rates of 1, 2, 5.5, 11, 6, 9, 12, 18, 24, 48, 54 and Super
AG Mode108-Mbps
Spreading DSSS (Direct Sequence Spread Spectrum)
Security 64(40h) bit, 128(104h) bit, WPA, IEEE802.1X, AES-OCB, AES-CCM,
Microsoft PEAP,TKIP, WEP
Antenna External 5dBi antenna
108 Mbps (only with
Belkin 54G or above
router that supports 108
Mbps speed) 200 ft (60.96 m) – Indoor
54 Mbps 200 ft (60.96 m) – Indoor
Throughput
11 Mbps 200 ft (60.96 m) – Indoor
Certifications Wi-Fi certified
North America: United States, Canada
Europe: Austria, Belgium, Cyprus, Denmark, Finland, France,
Germany, Greece, Iceland, Ireland, Italy, Liechtenstein, Luxembourg,
Netherlands, Norway, Portugal, Spain, Sweden, Switzerland, United
Kingdom
Australia
Certifications for use
by country
New Zealand
56,000 Kbps maximum downstream data Data Transmission
NOTE: 56 Kbps technology refers to download speeds only and
requires compatible modems at server sites. Other conditions may limit
modem speed. FCC limitations allow a maximum of 53 Kbps during
download transmissions.
Data Speeds (Upload only)
33,600/31,200/28,800/26,400/21,600/19,200/16,800/14,400/
12,000/9,600/7,200/4,800/2,400/1,200/300
Data Standards ITU-T V.90, ITU-T, ITU-T V.34, V.44, V.42, V.42bis21, V.32bis, Bell
212A, and Bell 103
Fax Speeds 14,400/12,000/9,600/7,200/4,800/2,400/300 b/s
Fax Mode
Capabilities ITU-T T.31 class 1 FAX, V. 17, V.29, V.27ter, and V.21 Channel 2
Error Correction and
Data Compression V.44, 42bis, V.42 and MNP2-5
Power Management ACPI; PPMI 1.1 and wake support with PME and Vaux; meets PCI 2.3
requirements and PC 2001 requirements
Agere 56K PCI
Modem
Upgradeability Driver upgradeable for future enhancements
