Page 27: Important
Page 27
SKU 99856-96154
for technical questions, please call 1-800-444-3353.
PARTS LIST/dIAGRAM - STARTER & cONTROL bOX
Part
description
Q’ty
Part
description
Q’ty
1
Clamp Ring
1
11
Control Rear Cover
1
Gasket
1
1
Attachment Bolt
1
3
Bolt (M4x10)
1
13
Protector
1
4
Control Front Cover
1
14
Fixed Mount
1
5
Diode
1
15
Spring
1
6
Nut (M4)
1
16
Cover
1
7
Fixed Mount
1
17
Protector Assy.
1
8
Ignition Switch
1
18
Bolt (M3x12)
9
Safety
1
19
Ignition Key
1
10
Diode Assy.
1
IMPORTANT
When ordering parts from the above Parts List, make sure to specify the following:
The MOdEL NuMbER (either 99856 or 96154) of the Engine for which you are ordering.
The PART NuMbER listed to the left of the part description.
The NAME Of THE PARTS LIST from which you are ordering (located at the top of this page).
a.
b.
c.
