Harbor Freight Tools 96154 - 11HP - Manual (Page 13)

Page 13 SKU 99856-96154 for technical questions, please call 1-800-444-3353.
PARTS LIST/dIAGRAM - cRANkcASE
Part description Q’ty Part description Q’ty
1 Washer 8 Washer
Drain Plug 9 Split Pin 1
3 Oil Seal, Crankshaft 1 10 Regulating Sway Bar 1
4 Seal 1 11 Nut (M10) 1
5 Diode 1 1 O-Ring 1
6 Crankcase 1 13 Bolt (M6x14)
7 Oil Seal, Regulating Sway Bar 1 14 Oil Sensor 1
IMPORTANT
When ordering parts from the above Parts List, make sure to specify the following:
The MOdEL NuMbER (either 99856 or 96154) of the Engine for which you are ordering.
The PART NuMbER listed to the left of the part description.
The NAME Of THE PARTS LIST from which you are ordering (located at the top of this page). a.
b.
c.
