SKU 99856-96154
for technical questions, please call 1-800-444-3353.
PARTS LIST/dIAGRAM - cyLINdER HEAd/cyLINdER HEAd cOVER
Part
description
Q’ty
Part
description
Q’ty
1
Bolt
1
11
Lead Wind Cover
1
Washer
1
1
Stud (M6x8x134.5)
3
Rubber Seal
1
13
Gasket, Cylinder Head
1
4
Bolt
1
14
Set Pin
5
Cylinder Head Cover Assy.
1
15
Cylinder Head Assy.
1
6
Gasket, Cylinder Head Cover
1
16
Spark Plug (F7RTCU)
1
7
Bolt
4
17
Stud (M8x48.5)
8
Circlip
1
18
Air Duct
1
9
Exhaust Valve Guide
1
19
Seal
1
10
Intake Valve Guide
1
20
Bolt (M6x12)
1
IMPORTANT
When ordering parts from the above Parts List, make sure to specify the following:
The MOdEL NuMbER (either 99856 or 96154) of the Engine for which you are ordering.
The PART NuMbER listed to the left of the part description.
The NAME Of THE PARTS LIST from which you are ordering (located at the top of this page).
a.
b.
c.
