Harbor Freight Tools 96154 - 11HP - Manual (Page 22)

Page SKU 99856-96154 for technical questions, please call 1-800-444-3353.
PARTS LIST/dIAGRAM - REcOIL STARTER
Part description Q’ty Part description Q’ty
1 Engine Switch 1 11 Ratchet Spring
Wire Grommet 1 1 Ratchet
3 Clip 1 13 Friction Spring 1
4 Plastic Clip 1 14 Set Screw 1
5 Bolt (M6x12) 5 15 Spring Lid 1
6 Fan Hood Assy. 1 16 Rope 1
7 Bolt (M6x8) 3 17 Handle 1
8 Casing 1 18 Recoil Starter 1
9 Coil Leaf Spring 1 19 Recoil Starter Assy. 1
10 Cord Spool 1
IMPORTANT
When ordering parts from the above Parts List, make sure to specify the following:
The MOdEL NuMbER (either 99856 or 96154) of the Engine for which you are ordering.
The PART NuMbER listed to the left of the part description.
The NAME Of THE PARTS LIST from which you are ordering (located at the top of this page). a.
b.
c.
