Page 14: Part description q’ty part description q’ty
Page 14
SKU 99856-96154
for technical questions, please call 1-800-444-3353.
PARTS LIST/dIAGRAM - cRANkcASE cOVER
IMPORTANT
When ordering parts from the above Parts List, make sure to specify the following:
The MOdEL NuMbER (either 99856 or 96154) of the Engine for which you are ordering.
The PART NuMbER listed to the left of the part description.
The NAME Of THE PARTS LIST from which you are ordering (located at the top of this page).
a.
b.
c.
Part
description
Q’ty
Part
description
Q’ty
1
Oil Plug with Seal
1
11
Washer
Oil Plug
1
1
Sliding Sleeve
1
3
Seal
1
13
Gasket, Crankcase
1
4
Crankcase Cover
1
14
Set Pin (8x12)
5
Washer, Drive Gear
1
15
Dipstick
1
6
Drive Gear, Regulator
1
16
Dipstick with Seal
1
7
Pin
17
Bearing (6206)
1
8
Regulating Shaft
1
18
Oil Seal, Crankshaft
1
9
Flying Block
19
Bolt (M8x40)
7
10
Snap Ring
1
20
Drive Gear, Regulator
1
