SKU 99856-96154
for technical questions, please call 1-800-444-3353.
PARTS LIST/dIAGRAM - cRANkSHAfT, PISTON, cONNEcTING ROd
Part
description
Q’ty
Part
description
Q’ty
1
Piston Ring (I)
1
1
Bearing (6202)
Piston Ring (II)
1
13
Balancing Shaft
1
3
Side Rail
14
Bearing (6207)
1
4
Expander
1
15
Woodruff Key
1
5
Scraper Ring Set
1
16
Crankshaft
1
6
Piston Pin Circlip
17
Drive Gear
1
7
Piston
1
18
Timing Gear
1
8
Piston Pin
1
19
Piston Ring Set Kit
1
9
Shank
1
20
Connecting Rod Assy.
1
10
Bearing Cap
1
1
Crankshaft Assy.
1
11
Bolt
IMPORTANT
When ordering parts from the above Parts List, make sure to specify the following:
The MOdEL NuMbER (either 99856 or 96154) of the Engine for which you are ordering.
The PART NuMbER listed to the left of the part description.
The NAME Of THE PARTS LIST from which you are ordering (located at the top of this page).
a.
b.
c.
