Page 18: Important
Page 18
SKU 99856-96154
for technical questions, please call 1-800-444-3353.
PARTS LIST/dIAGRAM - cARbuRETOR
Part
description
Q’ty
Part
description
Q’ty
1
Inlet Gasket
1
16
Choke Stem
1
Connecting Block
1
17
Airproof Washer
1
3
Carburetor Gasket
1
18
Throttle Lever
1
4
Idle Adjustment Screw
1
19
Washer
1
5
Mixture Chamber Body
1
20
Screw (M4)
6
Main Nozzle
1
1
Cover
1
7
Main Jet
1
Choke Switch
1
8
Float
1
3
Throttle Unit
1
9
Float Chamber Gasket
1
4
Spring, Mixture Adjustment Screw
1
10
Float Chamber
1
5
Mixture Adjustment Screw
1
11
Washer
6
Choke Unit
1
1
Float Chamber Drain Screw
1
27
Float Chamber
1
13
Screw
1
8
Carburetor Assy.
1
14
Air Cleaner Gasket
1
9
Float Needle
1
15
Choke
1
IMPORTANT
When ordering parts from the above Parts List, make sure to specify the following:
The MOdEL NuMbER (either 99856 or 96154) of the Engine for which you are ordering.
The PART NuMbER listed to the left of the part description.
The NAME Of THE PARTS LIST from which you are ordering (located at the top of this page).
a.
b.
c.
