Page SKU 99856-96154 for technical questions, please call 1-800-444-3353.
SPEcIfIcATIONS
Model 99856 Model 96154
Engine Type
13 HP, 4-Stroke Gasoline Engine
Air Cooled, Horizontal Shaft
Electric Start w/Recoil Back-Up
Powered w/mid-to-high octane
unleaded gasoline
Model: 188FD, Family: 6CLGS.38988F
Battery Type: 12 VDC (not included)
11 HP, 4-Stroke Gasoline Engine
Air Cooled, Horizontal Shaft
Electric Start w/Recoil Back-Up
Powered w/mid-to-high octane
unleaded gasoline
Model: 182FD, Family: 6CLGS.38988F
Battery Type: 12 VDC (not included)
Displacement 389CC 337cc
Compression Ratio 8:1 8:1
Maximum Power
Output
13 HP @ 3600 rpm 11 HP @ 3600 RPM
Maximum Torque 17 Ft.-Lb. @ 2500 RPM 15.5 Ft.-Lb. @ 2500 RPM
Fuel Tank Capacity 1.7 Gal. 1.7 Gal.
Engine Oil Capacity 2.3 Pints 2.3 Pints
Shaft Size
1” Diameter x 2-7/8” Long
Drilled & Tapped with 3/8”-4 UNF
1/4” Keyway
1” Diameter x 2-7/8” Long
Drilled & Tapped with 3/8”-4 UNF
1/4” Keyway
Engine Rotation Counterclockwise facing the Shaft Counterclockwise facing the Shaft
Spark Plug Type NGK ® BR-6HS / Champion ® RL86C NGK ® BR-6HS / Champion ® RL86C
Air Cleaner Type Semi-Dry Semi-Dry
Engine Approvals*
2008 U.S. E.P.A. Phase II
2008 California Emissions Regulations
2008 U.S. E.P.A. Phase II
Weight 68.3 Lb. 68.3 Lb.
IMPORTANT!
This product requires oil and fuel to be added before starting. Attempting to start the Engine
without oil WILL ruin the Engine and void the warranty.
NOTE:
The Engine’s carburetor may need to be adjusted by a qualified mechanic for efficient
high-altitude use.
* The emission control system for this Engine is warranted for standards set by the u.S.
Environmental Protection Agency for warranty information, refer to the last pages of this manual.
SAVE THIS MANuAL
You will need this manual for the safety warnings and precautions, assembly, oper-
ating, inspection, maintenance and cleaning procedures, parts list and assembly diagram.
Keep your invoice with this manual. Write the invoice number on the inside of the front
cover. Write the product’s serial number in the back of the manual near the assembly
diagram, or write month and year of purchase if product has no number. Keep this manual
and invoice in a safe and dry place for future reference.
REV 07g
