Chapter 10 | Customizing the HP Jornada| 95
To insert the CF card
1. Turn off the P/PC, and close the display cover.
2. Open the CF card door by pressing onto the fingernail
recess and flipping the door open.
3. Connect the P/PC to AC power.
4. Push the card, connector-side first, gently but completely
into the slot. The P/PC turns back on.
5. Replace the door by flipping it back into place.
If you want to use the CF card while on battery power, select
Yes in the PC Card detected in slot 1 dialog box.
View showing how to insert a CF card
To remove the CF card
1. Close all applications on the P/PC that have open files
on the CF card.
2. Turn off the P/PC, and close the display cover.
3. Open the CF card door by pressing onto the fingernail
recess and flipping the door open.
4. Use the end of the stylus to lever the CF card out. The
P/PC turns back on.
5. Replace the door by flipping it back into place.
