26 Ioline FlexJet E User Guide
The Control Center
Overview
The Control Center is a utility program that does two things:
n
Allows you to adjust settings to tailor output (e.g. scale, line
width) from the computer.
n Provides an interface to send completed files to the printer.
Figure 15. Control Center Main Menu.
Changing System Settings
A variety of settings are adjustable to fit specific needs:
n
Make sure the printer power is on and that the initialization
process is complete. The carriage will park, the keypad OK
light will turn red and the Square light will turn green.
n The Screen Menu displays the primary settings that are adjust-
able. The Menu Bar contains utilities for setting up the Control
Center and calibrating the printer.
n Changes only take effect after one of the Send buttons is
pushed.
To avoid communication port
conflicts, do not simultaneously
run more than one application
that communicates with the
printer.
Note
i
