38
Input/Output Signals
1. IEEE1394 interface (IEEE1394 connector)
1) Standard rating
1394-based Digital Camera Specification Ver.1.30 IIDC protocol
2) Transmit format
HV-F31F
Camera Mode Frame Rate bit/pixel bit/ch Format Mode(ID)
XGA (1024 x 768) YUV 15 16 8 1 3
XGA (1024 x 768) RGB 7.5 24 8 1 4
SVGA (800 x 600) NOTE １ YUV 30 16 8 1 0
SVGA (800 x 600) NOTE １ RGB 15 24 8 1 1
XGA (1024 x 768) RGB 3.3 48 10 7 6
800 x 600
768
1024
NOTE 1:
In the SVGA output format, the full
image data from the center SVGA range
are transmitted.
