Page 15
15
Your PC Workstation Does Not Start Correctly
Case 3 — Detected Hardware Error
Memory Installation
NOTE
Use only the HP memory modules provided for your PC Workstation model. If you
want to find out about available accessories for your PC Workstation, refer to the HP
Accessories Web site at:
Memory Expansion Card With RIMM Sockets
Memory Expansion Card With DIMM Sockets
Number of Sockets
Four sockets supporting ECC RDRAM modules
installed in pairs.
Four sockets supporting SDRAM 100 MHz ECC
modules installed in pairs.
Order of Installation
Fill the first two RIMM sockets A0 and B0.
Socket 0 is the one nearest to the processor(s).
Upgrades are installed in pairs using sockets A1 and
B1.
Fill the first two DIMM sockets A0 and B0.
Socket 0 is the one nearest to the system board.
Upgrades are installed in pairs using sockets A1 and
B1.
Unused Sockets
Unused A1 and B1 RIMM sockets must contain a
continuity module.
Continuity module is not required for unused DIMM
sockets. Sockets A1 and B1 can be left empty.
ECC Type
RDRAM ECC-type modules only used.
SDRAM ECC-type modules supported only.
Memory type
RDRAM modules must be installed in pairs and
contain the same HP part number.
SDRAM modules must be installed in pairs and
contain the same HP part number.
