HP 6212 - Manual (Page 7)

6212-A2-GB20-00 May 2004 7
Table of Contents
Chapter 1 Introduction ...................................................... 9
1.1 Product Overview ................................................................ 9
1.2 Features .......................................................................... 10
1.3 Application ....................................................................... 11
1.4 Front Panel LED Indicators.................................................. 12
Chapter 2 Hardware Installation...................................... 13
2.1 Installation....................................................................... 13
2.2 Installing the USB Driver .................................................... 14
2.3 Uninstalling the USB Driver................................................. 23
Chapter 3 Login Via the Web Browser .............................. 26
3.1 IP Address ....................................................................... 26
3.2 Login Procedure ................................................................ 27
Chapter 4 Basic Configuration.......................................... 28
4.1 Software Version Information.............................................. 28
4.2 Change the Password......................................................... 29
4.3 ADSL Link Status .............................................................. 30
4.4 WAN Setup....................................................................... 31
4.5 LAN IP Address ................................................................. 34
4.6 Routing............................................................................ 35
4.7 Save ............................................................................... 38
4.8 Reboot............................................................................. 38
4.9 Retrieve default settings..................................................... 39
Chapter 5 Advanced Configuration................................... 40
5.1 ADSL Mode....................................................................... 40
5.2 VLAN ............................................................................... 41
5.3 DHCP .............................................................................. 41
5.4 DHCP Relay ...................................................................... 44
5.5 SNMP .............................................................................. 45
5.6 Firewall............................................................................ 48
5.7 NAT................................................................................. 52
5.8 Configure ......................................................................... 54
5.9 VCC ................................................................................ 59
5.10 IGMP ............................................................................... 65
5.11 Bridging........................................................................... 66
Chapter 6 Performance monitoring .................................. 71
6.1 ADSL Link Status .............................................................. 71
