9.9 Top Hook Parts
Figure
No.
Part Name
Parts
Per
Hoist
200S
1
Top Hook Complete Assembly
1
ER2KS1011
2
Top Suspension Plate A Assembly
1
ER2KS5011
3
Top Suspension Plate B Assembly
1
ER2KS5012
4
Suspender Shaft B
4
E6S013150
5
Bottom Hook Assembly
1
ER2KS2121
6 Bottom
Hook
1
ER2KS9121
7 Thrust
Bearing
1
E6S038150
8 Bearing
Cover
1
E6S023200
9 Hook
Nut
1
E6S024200
10 Bottom
Yoke
1
E6S030200
11
Safety Latch Assembly
1
C2BA3001071
12 Stopper
Screw
A
1
J1TB01110016
13 Stopper
Screw
B
1
J1TB01110010
14 Bottom
Stay
Bolt
8
E6S038150
15
Bottom Idle Sheave Assembly
3
ER2HS5052
16 Thrust
Needle
Bearing
6
ER1HS9182
17
Shaft Stopper A
2
ER1IS9056
18
Top Shaft B
3
E6S067150
19
Shaft Stopper B
3
ER1JS9060
20 Guide
Roller
8
E6S062075
21 Bottom
Collar
8
E6S065150
22 Nut
16
9093445
23 Spring
Washer
16
9012717
24 Socket
Bolt
10
9091271
25 Spring
Washer
10
9012711
26
Connection Yoke Assembly
2
ER2IS5005
