9.2 Gearing Parts
Figure
No.
Part Name
Parts Per
Hoist
080S 100L 100S 150S 200S
1
Load Sheave Assembly
1 (2)
ER2FS6241
2
Load Sheave
1 (2)
ER2FS9241
3
Oil Seal
1 (2)
ER2ES9221
4
Ball Bearing
1 (2)
9000610
5
Ball Bearing
1 (2)
9000405
6
Load Gear
1 (2)
ER2FS9240
7
Snap Ring
1 (2)
9047150
8
Ball Bearing
1 (2)
9000110
9
Oil Seal
1 (2)
ER2ES9244
10
Ball Bearing
1 (2)
9000303
11
Oil Seal
1 (2)
ER1DS9233
12
Pinion Assembly
F
1 (2)
ER2FS5220
M ER2FS5304
13
Socket Bolt
3 (6)
9091249
14
Friction Clutch Complete Assembly
F
1 (2)
ER2HS1223 ER2IL1223 ER2FR1223 ER2HS1223 ER2IL1223
Friction Clutch With Mechanical
Brake Complete Assembly
M ER2FS1274
15
Wave Washer
1 (2)
ER2ES9234
16
Nut Cover
1 (2)
ER2ES9235
17
Name Plate FP (Adjustment Of
Friction Clutch Prohibited)
1
(2)
ER1BS9892
18
Gear B Assembly
F
1 (2)
ER2FS5262
M ER2FS5306
19
Gear Holder Plate Assembly
1 (2)
ER2FS6261
20
Gear Holder Plate
1 (2)
ER2FS9261
21
Ball Bearing
1 (2)
9000203
22
Ball Bearing
1 (2)
9000202
23
Set Pin S
2 (4)
ES120010S
24
Socket Bolt
3 (6)
9091275
25
Spring Lock Washer
3 (6)
9012711
27
Vent Cap
M
1 (2)
ER1BS1175
28
Snap Ring
M
1 (2)
9047111
29 Pawl
M
1
(2)
L4155015
30
Pawl Spring
M
1 (2)
ER1BS9290
31
Pawl Shaft
M
1 (2)
ER2CS9289
32
Pawl Shaft Washer
M
1 (2)
ER2CS9294
*Quantities in “( )” are for dual-body hoists.
