9.6 Electric Parts (Dual Speed)
Figure
No.
Part Name
Parts Per
Hoist
080SD 100LD 100SD 150SD 200SD
1
Limit Switch
Complete Assembly
1
(2)
ER2CI1060
2
Socket Bolt
3 (6)
9091247
3
Spring Lock Washer
3 (6)
9012709
4
LS Harness
1 (2)
ER2CI9554
5 Plate
Assembly
M, 2V
1 (2)
ER2LHE20I5A2
F, 2V
1 (2)
ER2BHE20I5A2
M, 4V
1 (2)
ER2LHN20I5A2
F, 4V
1 (2)
ER2BHN20I5A2
6 Plate
1
(2)
ER2EI9441
7
Plate Screw
3 (6)
ER1BS9445
8 Bushing
1
(2)
ECP99JBAC
9 Inverter
Assembly
M, 2V
1 (2)
INV637E24
F, 2V
INV637E21
M, 4V
INV637N24
F, 4V
INV637N21
10
Interface Board
1 (2)
ECP91KB02
11
Board Support
1 (2)
ECP99BKAA
12 Transformer
2V
1 (2)
TRF32C612
4V TRF32N612
13 Rectifier
1
(2)
ECP94DIAA
14
Terminal Block 6P
1 (2)
ECP1306AF
15 Terminal Block
Holder
1
(2)
ER2ES9466
16
Flat Head Machine
Screw
2
(4)
9096528
17
Machine Screw
2 (4)
9798512
18
Fulcrum Pin
1 (2)
ER2CS9449
19
Cover Suspender
1 (2)
ER2CS9456
20
Cover Belt
1 (2)
ER2CS9457
21
Socket Bolt
1 (2)
9091249
22
Plain Washer
1 (2)
ER1BS9436
23
Spring Lock Washer
1 (2)
9012709
24
Packing C
1 (2)
ER2FS9117
25
Controller Cover
Assembly
2V
1 (2)
ER2FI2104
4V ER2FI1104
26
Controller Cover
1 (2)
ER2FI9104
27
Resistor Cover
1 (2)
ER2EI9185
28 Braking
Resistor
2V
1 (2)
INV735E16
4V INV735Y16
29
Name Plate B
1 (2)
ER2BHM20I9A5
30
Pan Head Machine
Screw
2
(4)
9798534
31
Socket Bolt
4 (8)
9091254
32
Toothed Lock
Washer
4
(8)
9679709
*Quantities in “( )” are for dual-body hoists.
